Short Description
Model No.: BVST 2500LB-6 Clicks: 1773
API 6D Forged Ball valve 2500LB RTJ flange end, side entry trunnion mounted type, bolted bonnet, gear operator. Model Size: 6 Inch.
Standards:
Body/Bonnet: ASTM A105
Ball: ASTM A105+ENP
Seat: Devlon
Stem: ASTM A105+ENP
Face to face dimentision: 927mm
Valve standard: API6D
Flange standard: ASME B16.5
Sealing pressure test: 469BAR
Shell pressure test: 639BAR
Forged Side Entry Trunnion Mounted Ball Valve Key Feature and Ranges
- Design basis and product range: API6D/API608/GB/T12237.
- Face-to-face dimension: ASME B16.10/GB/T12221.
- Flanged ends: API605/ASME B16.47/GB/T9113.
- Butt-welding ends: ASME B16.25/GB/T12224.
- Wall thickness: ASME B16.34.
- Fireproof test: API607.
- Inspection and test: API6D/API598 JB/T9092.
- Valve size: 4" - 64", DN100 - DN1600.
- Materials of main parts: A105.LF2, F11, F22, F304, F316, F51.
- Seat materials: PTFE, RTFE or metal hard seal.
Forged Side Entry Trunnion Mounted Ball Valve Design Features
- ISO5211 platform design is adopted for the convenience of installing the actuator.
- Double block and bleed function.
- Anti-blow-out stem design.
- The pressure balancing hole is provided on the steel ball.
- The body is provided with a device for cleaning the valve cavity.
- Automatic pressure relief function.
- Fireproof and antistatic design.
- Sealant injection system for emergency seal.
- Multiple driving modes facilitate the realization of automatic control.
- Reliable stem seal and low operating torque. Metal hard seal seat can be made according to requirements.
