Actuator Gate Valve, Flange End, 150LB, ASME B16.5

Actuator Gate Valve, Flange End, 150LB, ASME B16.5
Short Description
 Model No.: GVRF 150LB-48    Clicks: 1070
China Actuator Gate Valve manufacturer Valmax provides Actuator Gate Valve, Flange End, 150LB, API 600, ASME B16.5, DN50-1200mm, in ASTM A216 WCB.
Keywords: Gate Valves .

Actuator Gate Valve, Flange End, 150LB, ASME B16.5 Key Specifications / Features

Actuator gate valve being widely used to connect or cut off medium in pipeline can only be opened or closed fully. Gate valve has the advantages of installing at any direction without limitation, small disturbed current, low pressure drop, shot face-to-face dimension, good sealing performance and wide application. Otherwise, the feature of the gate valve can ensure permissible leakage rate lower than that specified in API 6D or API 600 and the middle shaft sealing can pass the USA VOC leakage test. China Valmax Valve can provide various materials specified by API 600. We can also provide valves made of carbon steel, stainless steel, alloy, Hastelloy and nickel chrome to meet the different requirements.

Performance
Body/bonnet ASTM A216 WCB
Wedge ASTM A216 WCB+13CR
Seat ASTM A105+13CR
Stem 13CR
Face to face dimension 863mm
Structural dimension 2″-48″, DN50-1200
Pressure rating Class 150-2500LB, PN16-420Bar
Valve standard API 600
Flange end ASME B16.5

- Certified to API600
- USA VOC middle shaft micro leakage certification
- Design of outside screw and yoke
- Bolted bonnet
- Pressure self-sealing type bonnet
- Design of wedge type flexible gate and full guide rail
