API 600 ASTM A351 CF8 Gate Valve, BB OS&Y 24 Inch 600LB

Valmax > Valves > Gate Valves > Cast Steel Gate Valves > API 600 ASTM A351 CF8 Gate Valve, BB OS&Y 24 Inch 600LB
API 600 ASTM A351 CF8 Gate Valve, BB OS&Y 24 Inch 600LB
Short Description
 Model No.: GVBB 600LB 24     Clicks: 3900
China API 600 Gate Valve manufacturer Valmax supplies ASTM A351 CF8 Rising Stem Bolted Bonnet Gate Valves, Gear operated, RF Flanged, OS&Y, 24 Inch, 600LB.
Request a quote
Keywords: Gate Valves .
Previous: Outside Screw and Yoke Gate Valves, 600 LB, 2 Inch
Next: Actuator Gate Valve, Flange End, 150LB, ASME B16.5

API 600 ASTM A351 CF8 Gate Valve, BB OS&Y 24 Inch 600LB Key Specifications / Features

Gate Valve 24", 600LB, RF Flange End, OS&Y, Bolted Bonnet, Rising Stem, Gear Operator.
Body/Bonnet: ASTM A351 CF8.
Wedge: ASTM A351 CF8  +STL.
Seat: ASTM 304SS+STL.
Stem: F316L.
Face to Face Dimension: 1397mm.
Valve Standard: API 600.
Flange Standard: ASME B16.5.
Sealing Pressure Test: 113BAR.
Shell Pressure Test: 154BAR.
