Short Description
Model No.: BVF 150LB-10*8 Clicks: 1234
Reduced Port ball valve, 10"X8" 150LB, RF flange end, T-type three way floating ball type, bolted bonnet, gear operator.
Model: 10 Inch by 8 Inch, 150 LB.
Body/Bonnet: ASTM A216 WCB.
Ball: ASTM A182 F316.
Seat: PTFE.
Stem: ASTM A182 F316.
Face to face dimentision: 730 mm.
Valve standard: API 6D.
Flange standard: ASME B16.5.
Sealing pressure test: 169 BAR.
Shell pressure test: 230 BAR.
Standarda and range:
- Design basis and product range: API 6D, API 608, GB/T 12237.
- Face-to-face dimension: ASME B16.10, GB/T 12221.
- Flanged ends: API 605, ASME B16.47, GB/T 9113.
- Butt-welding ends: ASME B16.25, GB/T 12224.
- Wall thickness: ASME B16.34.
- Fireproof test: API 607.
- Inspection and test: API 6D, API 598, JB/T 9092.
- Product range: 4" - 64", DN100 - DN1600.
- Materials of main parts: WCB, LCB, WC6, WC9, CF8, CF8M.
- Seat materials: PTFE, RTFE or metal hard seal.
Design features:
- ISO5211 platform design is adopted for the convenience of installing the actuator.
- Double block and bleed function.
- Anti-blow-out stem design.
- The pressure balancing hole is provided on the steel ball.
- The body is provided with a device for cleaning the valve cavity.
- Automatic pressure relief function.
- Fireproof and antistatic design.
- Sealant injection system for emergency seal.
- Multiple driving modes facilitate the realization of automatic control.
- Reliable stem seal and low operating torque. Metal hard seal seat can be made according to requirements.
