API 6D Hydraulic Actuated Ball Valves, Trunnion Mounted

Valmax > Valves > Ball Valves > Trunnion Mounted Ball Valves > API 6D Hydraulic Actuated Ball Valves, Trunnion Mounted

Short Description

Model No.: BVSTHA 600LB-16 Clicks: 1790

Cast steel hydraulic actuated ball valve 600LB RF, side entry, trunnion mounted, 3 pcs type, hydraulic actuator.
Model size: 16".
Body/Bonnet: ASTM A216 WCB.
Ball: ASTM A182 A105+ENP.
Seat: DEVLON.
Stem: ASTM A182 F6a.
Face to face dimension: 991mm.
Valve standard: API 6D.
Flange standard: ASME B16.5.
Sealing pressure test: 110BAR.
Shell pressure test: 150BAR.

Request a quote PDF

Keywords: Ball Valves , API 6D Ball Valves , Hydraulic Actuated Ball Valves , Hydraulic Actuated Valves .

Previous: 2-PC Cast Steel Trunnion Mounted Ball Valves 600LB
Next: API 6D Forged Steel Ball Valves, ASTM A105

API 6D Hydraulic Actuated Ball Valves, Trunnion Mounted Key Specifications / Features

Key Feature and Ranges:
- Design basis and product range: API 6D / API 608 / GB/T 12237.
- Face-to-face dimension: ASME B16.10 / GB/T 12221.
- Flanged ends: API605/ ASME B16.47 / GB/T 9113.
- Butt-welding ends: ASME B16.25 / GB/T 12224.
- Wall thickness: ASME B16.34.
- Fireproof test: API 607.
- Inspection and test: API 6D / API 598 JB/T 9092.
- Product range: 4" - 64", DN100 - DN1600.
- Materials of main parts: WCB, LCB, WC6, WC9, CF8, CF8M.
- Seat materials: PTFE, RTFE or metal hard seal.
